NX-D15NT4T10

SKU: AHZ Category:

Multi Loop PID Controller

£898.50 ex. VAT

Description

Network Instrumentation Modules make optimal distributed configuration a reality. Distributed modules execute cooperative control using Ethernet connectivity. This instrumentation offers an excellent solution for productivity and energy conservation needs.

A variety of input sampling cycles and input accuracy levels are available, depending on the model.

  • Sampling cycles: 100ms, 200ms and 500 ms.
  • Input accuracy: ±0.1% FS and ±0.3 &FS

Compact digital controllers with advanced functions can execute 2-loop or 4-loop control.

Control output can be selected from among transistor output, DC current, DC voltage output, and motor driver output  (available soon).

Optionally, 4 current transformer inputs, 4 digital outputs, or 4 digital inputs are also available.

Since the SLP-NX Smart Loader Package can be connected via Ethernet, Network Instrumentation Modules can be set up and monitored over an Ethernet communications network.

Features

  • Ethernet and RS-485 as standard features
  • Up to 4 control loops per module
  • Side connectors for reduced wiring
  • Support for reduced wiring daisy-chain connection and distributed layout
  • Full multi-range input for thermocouple, RTD, DC current and DC voltage.
  • 2-loop control  (with RSP) or cascade control (available soon), depending on the control mode.
  • Heat/cool control using a combination of control outputs
  • Control output branching for multiple actuators
  • 6 LED indicators (standard), and additional LEDs depending on the model, provide abundant status information
  • 3-part structure for easy maintenance
  • Equipped with input/output broken line approximation for nonlinear processes
  • 4 additional CT/DI/DO points optionally available
  • Logical operation processing for DI/DO and internal events
  • Data transfer function allows operation input/output between modules
  • Multi-loop cooperative control with supervisor module







Additional information

Download the technical document for this product below.


Download Technical Datasheet
Weight 0.2 kg
